Automatic Glue Dispenser with PLC Touch-Screen Control and Roller Conveyor for Adjustable Mixing Ratio 2:1-5:1

Certification : CE、ISO 9001

Product Width : 200mm-1300mm (customizable)

Price : Online/offline communication

Control Method : PLC programming+touch screen

Conveyor Line : Width 1300mm, height 850mm ± 50mm, length customizable

Delivery Time : 20-35Work days

Adhesive Viscosity : 4000-12000CPS (customizable)

Weight (approximately) : 500 KG

Temperature Adjustment Range of Material A Tank : Adjustable from 20-30 ℃

Payment Terms : T/T

Glue Consumption per Square Meter : Adjustable from 200g to 450g

Gel Dripping Length : 300mm-4500mm (customizable)

Packaging Details : Film with Foam

Ratio Adjustment : The mixing ratio can be adjusted between 2:1-5:1

Power : 5.75kw

Gel Dripping Width : 200-1300mm (customizable)

Place of Origin : China

Coating Speed : 1-12 meters/minute (adjustable)

MOQ : 1

Environmental Requirements : Temperature 5-45 ℃, humidity ≤ 80%

Brand Name : Henrriet

Overall dimensions : 1500*880*1700mm

Effective Volume of AB Tanks : 40L (automatic feeding)

Contact Now

Honeycomb Panel Glue Dispenser for Small Panels
PLC Touch-Screen Control, Roller Conveyor, Automatic Gluing Equipment for Aluminum Honeycomb Composite Panels
Product Overview
This automatic glue dispensing unit is designed for the lamination process of small-to-medium-sized panels. It features an industrial frame-type main body with an integrated roller conveyor. The operation interface and the gluing zone are arranged separately, and the overall design is compact and well organized, facilitating flexible placement within factory settings.
The machine performs automatic proportioning and application of two-component adhesives, replacing traditional manual gluing methods. It is compatible with two-part adhesives of various viscosity levels. A built-in PLC and touch-screen control architecture enables all operational settings to be configured through the human-machine interface. The system supports continuous gluing for small panels of varying dimensions and meets the adhesive application requirements in sandwich panel production.
Key Features
  • Superior Production Capacity: Adjustable dispensing speed, adhesive mixing ratio, and glue consumption per unit area. Customizable conveyor structure for multiple panel sizes. Automated process reduces variability and ensures consistent coating.
  • Security Guarantee: Designed to industrial safety standards with partitioned electrical components. Physical barrier between operator station and dispensing zone. Basic fault indication with alert messages on touch screen.
  • Application Areas: Suitable for gluing processes before panel lamination, including honeycomb panels and composite bonding for various door products.
  • Maintenance and Upkeep: Easy cleaning of dispensing nozzles and conveyor surfaces. Periodic inspection of adhesive pipelines and scheduled checks on drive assemblies and electrical components.
Technical Specifications
Specification Details
Gel Dripping Width 200-1300mm (customizable)
Coating Speed 1-12 meters/minute (adjustable)
Gel Dripping Length 300mm-4500mm (customizable)
Product Width 200mm-1300mm (customizable)
Ratio Adjustment Mixing ratio adjustable between 2:1-5:1
Environmental Requirements Temperature 5-45 ℃, humidity ≤ 80%
Effective Volume of AB Tanks 40L (automatic feeding)
Glue Consumption per Square Meter Adjustable from 200g to 450g
Conveyor Line Width 1300mm, height 850mm ± 50mm, length customizable
Temperature Adjustment Range of Material A Tank Adjustable from 20-30 ℃
Adhesive Viscosity 4000-12000CPS (customizable)
Power 5.75kw
Control Method PLC programming + touch screen
Company Advantages
  • Two In-House Factories: Better prices and faster delivery with no middlemen markups
  • 30+ Senior Engineers: Custom-built solutions designed around your production needs
  • CE & ISO 9001 Certified: Global-ready equipment meeting international standards
  • 50+ Countries, 1000+ Projects: Proven experience in design and manufacturing
Service Support
  • Warranty: 1 year
  • Packaging: Film with foam
  • 24-hour customer service hotline
  • Respond to repair needs within 48 hours
  • Free video training for operators
  • Process guidance manuals provided
  • Lifetime technical support and software upgrade services
Product Image
Automatic Glue Dispenser with PLC Touch-Screen Control and Roller Conveyor for Adjustable Mixing Ratio 2:1-5:1
Company Introduction
Automatic Glue Dispenser with PLC Touch-Screen Control and Roller Conveyor for Adjustable Mixing Ratio 2:1-5:1 Automatic Glue Dispenser with PLC Touch-Screen Control and Roller Conveyor for Adjustable Mixing Ratio 2:1-5:1 Automatic Glue Dispenser with PLC Touch-Screen Control and Roller Conveyor for Adjustable Mixing Ratio 2:1-5:1 Automatic Glue Dispenser with PLC Touch-Screen Control and Roller Conveyor for Adjustable Mixing Ratio 2:1-5:1 Automatic Glue Dispenser with PLC Touch-Screen Control and Roller Conveyor for Adjustable Mixing Ratio 2:1-5:1 Automatic Glue Dispenser with PLC Touch-Screen Control and Roller Conveyor for Adjustable Mixing Ratio 2:1-5:1 Automatic Glue Dispenser with PLC Touch-Screen Control and Roller Conveyor for Adjustable Mixing Ratio 2:1-5:1 Automatic Glue Dispenser with PLC Touch-Screen Control and Roller Conveyor for Adjustable Mixing Ratio 2:1-5:1
Frequently Asked Questions
Who are we?
We are based in Guangdong, China, starting from 2016. We sell to Domestic Market (55.00%), Africa (20.00%), South Asia (9.00%), Central America (6.00%), Oceania (5.00%), South America (3.00%), and Eastern Asia (2.00%). We have over 110 employees.
Why should you buy from us not from other suppliers?
With more than 20 years in the wooden machinery industry, we have two factories covering over 20,000 square meters. Our team includes over 130 professional employees, including a senior design team of 30+ engineers. We provide custom machine design drawings, comprehensive installation, commissioning, and operator training to ensure immediate production upon arrival.
How can we guarantee quality?
We confirm required functions through customer communication, complete machine drawing design according to requirements, provide on-site guidance for cutting, welding, and assembly operations, conduct full process testing of each machine's functionality, and perform final inspection before shipment.
What can you buy from us?
We offer hydraulic cold presses, single-layer and multi-layer hot presses, glue spreading machines, automatic feeders, turnover machines, automatic palletizers, and non-standard automated production lines of various specifications.
What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, Express Delivery. Accepted Payment Currency: USD, EUR, CNY. Accepted Payment Type: T/T, L/C, PayPal, Western Union, Cash. Languages Spoken: English, Chinese, Spanish, Japanese, Russian, Hindi.
